Huawei E5377 4G LTE Mobile Hotspot

Huawei adds its router family with a new model E5377, which is a new LTE "pocket-Hotspot" with small size. Here, the Huawei E5377 is not only with fast LTE category 4, but also with its low price points.

Features and characteristics of Huawei E5377
Manufacturer and model	Huawei E5377
Chipset:	HiSilicon B710AM
LTE Category:	CAT4
Download rate up:	Up to 150 MBit/s
Upload rate to:	Up to 50 MBit/s
Supported LTE bands:	800 /850/900/1800/2100/2600 MHz
Backward compatible with:	UMTS; GSM; HSPA+
Support of LTE-Advanced:	No
MIMO Support:	MIMO 2x2
External antenna connector:	yes, 2 TS-9 jacks (Buy Huawei E5377 Antenna)
Category:	LTE modem category 3 (3GPP Release 8)
Telephone
With integrated telephone system:	No
Connector for ISDN telephones:	No
Connection for analog telephones:	No
DECT:	No
integrator answering machine:	No
Network | LAN & WLAN
LAN Ports:	No
WLAN Standards:	Wi-Fi 802.11a / b/g/n (866 Mbit/s)
5 GHz WLAN support:	Yes
Encryption:	WEP, WPA, WPA2
Wireless Internet Hotspot function:	yes - for up to 10 devices
Others
Battery pack:	1500 mAh; interchangeable (to 6 hours of web browsing)
Dimension:	93.5 x 57.1 x 14.4 mm at 82 g
USB:	Micro-USB 2.0
Memory card expansion:	Yes; Micro-SD up to 32GB
Release:	November 2014
available at:	www.4gltemall.com

Technical Features   The Huawei E5377 offers download speeds up to 150 Mbit/s and 50 Mbit/s upload through its LTE Modem category 4, assuming a corresponding LTE tariff. The LTE networks in Germany, Austria and Switzerland are supported on 800, 1,800 and 2,600 MHz. If no LTE available, the router also comes with the mobile radio standards GPRS, UMTS or DC-HSPA+ with speeds of up to 42.2 Mbit/s (download) and 5.7 Mbit/s (upload).     Wireless repeater function The Wi-Fi standards a/b/g/n is supported on 2.4 and 5 GHz; THE faster Wi-Fi ac is unfortunately not supported. Up to 10 devices can be supplied by Huawei E5377 with wireless Internet, another via USB. In addition, a wireless repeater is integrated into the E5377, which switches automatically from the wireless coverage to a known wireless LAN network when it is available. Access via browser or app The hotspot is the smartphone controllable via the Huawei App "Mobile WiFi", available for both Android and iOS. Access to the web interface of the router is also obtained through a browser. The operating systems Windows XP / Vista / 7/8 / 8.1, Mac OS X will be supported from version 10.7 and Linux.   Informative display The 1.45-inch TFT LCD display indicates the type, the name and strength of the cellular network, the communication direction (upload / download), the repeater function and battery status, as well as the number of connected devices, the name of the WLAN network, the connection time and the transmitted data volume.   Connector for external antennas On the bottom of the email, with 9.4 x 5.7 x 1.4 centimeters and very compact with only 82 grams to slight router, two connectors for external UMTS/HSPA+/LTE antennas can be found next to the microUSB port. With matching adapter, SMA antenna can be used to increase the data rate mainly in the house. On the top, the menu button is to get information or make adjustments. Battery weak, but interchangeable The Huawei E5377 has a micro SD slot which accepts cards up to 32 GB capacity. The replaceable battery is only 1,500 mAh; and the surf time of up to 6 hours and a standby time (without WLAN) of up to 300 hours. Therefore it’s recommended to carry a spare battery. It comes with only a micro-USB USB cable, but no external power supply adapter - here you have to recharge by connecting it to a PC like smartphones.   Availability The Huawei E5377 is available in black or white at the online store www.4gltemall.com. If you like this new mobile hotspot, welcome to purchase from 4gltemall.com.

Huawei B310 LTE CPE Review

Huawei released a new stationary router for the LTE networks. It’s named Huawei B310. The exact model number for the European market is Huawei B310s-22, in this version the B310 could support all important frequency bands for LTE, UMTS and GSM. As a highlight, the maximum speed on LTE is 150 Mbit/s in the downlink (LTE Category 4); there is not only a Gigabit Ethernet port for the connection of an analog telephone, but also a port for quick connection of the router to the local network.





The Huawei B310 is in the entry-level segment both on the price as well as the level of equipment; the top model is the Huawei E5186 with a further significant better equipment, but also a higher price. Here now the Huawei B310 is available in China, we suppose it would be available in many markets worldwide. A major criticism of many recent LTE router models was the LAN interface, which is limited to 100 Mbps, while the built-in modem could often use up to 150 MBit/s. This of course is complete nonsense, because you have installed an annoying bottleneck in a modern device. On Huawei B310, the problem no longer exists fortunately: there is a Gigabit LAN port on the back of the router, so you can fully utilize the maximum of 150 Mbit/s of the LTE connection. Unfortunately, only one LAN port is installed, if you want to connect more than one device per cable must hang a switch behind the router.







On the back, there are connectors for LAN, telephone, external antenna and SIM card. The design of the B310 is very simple and user can easily identify the functions for the ports. There are two connectors for external antenna like Huawei B593, it could support 2 x 2 MIMO, which could improve the performance for network connection. The connector type is SMA, which are protected by a plastic cover. Even the SIM card slot is protected by a cover. If you want to buy the antenna for Huawei B310, you could check this one: http://www.4gltemall.com/4g-antenna-two-sma-connector.html . Instead of a current wireless ac module, the Huawei B310 installed a WLAN 802.11b/g/n radio module, which operates only on the 2.4 GHz band.





The Huawei B310s-22 has one RJ-11 port for an analog telephone. What kinds of telephone over are possible, but is not yet known. Telephone would be possible either natively over the air or over the internet via VoIP. The latter would have to access a VoIP provider in the web interface of the B310.



The Huawei B310 is available in black or white, as you can see in the pictures here in the article. On the front there are LEDs for reception, Power, data connection, telephone and Wi-Fi. On the top of the unit, there is a power button and a WPS button. Pressing both buttons simultaneously, the previous software version is automatically installed according to Huawei. The Huawei B310 is now available on www.4gltemall.com , if you are interested in this model, welcome to have a check or inquiry.
